Do you gap Trex decking

All deck boards must always be installed with a 6mm side-to-side gap. The Trex Hideaway Hidden Fasteners automatically measure the 6mm gap between grooved edge boards but you must still ensure the 6mm gap with the square edge boards.

Does Trex decking have gaps?

For Trex decking, the recommended end-to-end and side gaps range from 1/8 inch to 3/16 inch, depending on the temperature during installation. The gap against the permanent structure ranges from 1/4 inch to 1/2 inch, depending on the installation temperature.

What is the recommended spacing for Trex decking?

Most composite and PVC decking brands, like Trex and Azek, recommend a maximum joist spacing of 16 inches OC. Some brands, like WearDeck, let you get away with more – reinforced with a layer of fiberglass on both the top and bottom, WearDeck boards easily allow for spans of 24 inches OC.

Do you leave a space between composite deck boards?

One of the most critical steps for properly securing composite decking in place is to make sure you have a 1/4-inch to 3/16-inch gap between the decking boards (don’t exceed 1/2 inch). … Second, because composite decking expands in hot weather, the space ensures that extra stress won’t be placed on the fasteners.

Does Trex decking expand?

Yes, composite decking materials do expand and contract in all directions, but not as much as real wood. Composites are resistant to moisture. Instead, they change in size due to temperature. It will expand when under a hot temperature, while it will contract in the cold.

Why is there a space between deck boards?

The most important reason to have a spacing gap is to allow the boards the room to expand and contract naturally. Wood, by nature, expands and contracts when there are seasonal humidity changes and the wood begins to absorb or expel moisture.

Should deck boards be butted together?

We recommend butting treated deck boards together because as the moisture dries from the wood, the boards will shrink and naturally form gaps to allow water drainage. (Depending on moisture content, cedar, cypress and especially hardwood decking may require deliberate spacing for consistent joint sizes.)

How do you stagger Trex decking?

“Stagger your boards so their ends are in different spots.” Slide the next board in so it’s parallel to the first. The sliding motion is important, as you want the spacer to fit in the groove of this board, too. Basically, you’ll have two boards with the spacer between them.

How do you hide the ends of Trex decking?

Composite decking ends can be finished by picture framing, raised fascia board, painting the ends, attaching decking veneer, composite nosing strips, vinyl stair nosing cove, composite corner trim or plastic end caps.

How many stringers Trex steps?

Composite deck stairs are typically made from 2 x 12 pressure-treated stringers spaced about 8 to 16 inches apart. They rest on a solid foundation and are attached to the deck with hangers.

Article first time published on

Does composite decking shrink or expand?

Any composite decking will expand and contract, its really just a matter of how much it expands and contracts and at what temperatures. For most composite decking there is neglible expansion and contraction in the width of the board, however the expansion and contraction occurs in the length of the board.

What happens if deck boards are too close together?

When the deck boards are too close together, water won’t drain properly and air does not circulate. Your deck boards stay wet causing rot and that can lead to structural failure/ wood rot. … To widen the gap between the deck boards run the saw forward lightly touching one side, then check for clearance.

What happens if you don't space deck boards?

Without the right deck spacing, the boards may expand, cup, and buckle out of place. As a result, you may have to replace broken decking, or reinstall the boards with wider spacing to prevent further cupping and buckling, which can be time consuming and expensive.

What is the best gap between decking boards?

Proper Gap between Decking Boards When installing decking boards, make sure to leave 1/4 to 1/8 inch gaps in between them. This gap will make sure that the decking can breathe, have sufficient drainage, and make it easier to clean.

Do composite deck boards expand?

As temperatures fluctuate, composite deck boards will naturally experience thermal expansion and contraction. That’s why the board ends should never be installed tight against one another. … Then, install a fastener in the middle of each board length to prevent shifting during thermal expansion and contraction.

Do you have to seal the ends of Trex boards?

Kim Katwijk The cut ends of composite decking will absorb moisture and can swell, as shown here. Sealing the end cuts with lumber wax will help prevent swelling. … Because the uncapped ends of the boards are free to pick up water, the core can absorb moisture, which can lead to all sorts of problems.

How do you fill gaps in composite decking?

Fill small holes, using a putty knife, with a mixture of fine composite board shavings and silicone caulk. The consistency of the mixture should be thick enough that it will not seep out of the bottom of the hole. Match the color of the caulk to the deck boards.

How far do I space deck boards?

Proper wood deck board spacing should have at least a 1/8 inch gap after the decking has dried out. If you install your wood or treated deck boards while they are still wet boards, then they should be attached without a gap between them.

How far apart should composite deck clips be?

Check the decking specifications and local building codes for joist spacing. The most common is 16 inches on center. For a more rigid feel, 12 inches on center. Install blocking between each joist every four to six feet to reduce movement up and down and twisting of the joists, using exterior screws.

How far apart can stringers be?

Stringers should be spaced no more than 36 inches apart from each other for maximum stair support, according to the International Association of Certified Home Inspectors.

How far can a 5 4 deck Board Span?

Decking boards span from joist to joist. If you use 5/4 decking, joists must be no farther apart than 16 inches. Decking made of 2x4s or 2x6s can span up to 24 inches. If you will run decking at an angle, you might need to put the joists closer together.

Where do you start laying composite decking boards?

To install composite decking with a hidden fastening system, start at the house by face-screwing the first board. Next, screw a hidden fastener clip into the groove on top of each joist. Then, slide the groove of the next board into the clips and tighten with a rubber mallet.
