Why would you use a contactor

Why are Contactors Used? Contactors are used for high power applications. They allow a lower voltage and current to switch a much higher power circuit, so they are generally larger and more heavy-duty than control relays, enabling them to switch higher power loads on and off for many thousands of cycles (Figure 1).

What is the purpose of a contactor?

A contactor is a special type of relay used for switching an electrical circuit on or off. They are most commonly used with electric motors and lighting applications.

What is the advantage of contactor?

Advantages of contactors include: Protection. Simple Operation. High-load capacity.

Do I need to use a contactor?

As we mentioned above, the primary situation in which you’ll want to use a contactor is in any high-powered circuit in which an overload condition is likely to occur. This is particularly true if subsequently leaving the circuit in an energized state will create a hazardous environment for people and/or equipment.

When would you use a contactor instead of a relay?

Relays are used to control contacts of an electrical circuit due to a change of parameters or conditions in the same circuit or any other associated circuit. Contactors, on the other hand, are used to interrupt or establish connections in an electrical circuit repeatedly under different conditions.

How do electrical contacts work?

An electrical contact a switch that uses a secondary, low-voltage power source to complete or interrupt circuits that affect an electrical current. Unlike relays, they carry higher circuit loads and connect directly to high-voltage feeds, and they don’t interrupt short circuits like circuit breakers.

What are two basic types of contactors?

There are different types of contacts in a contactor, and they are; auxiliary contact, power contact, and contact spring. The power contact has two types that are; stationary and movable contact.

What is the purpose of a relay?

Relays are switches that open and close circuits electromechanically or electronically. Relays control one electrical circuit by opening and closing contacts in another circuit. As relay diagrams show, when a relay contact is normally open (NO), there is an open contact when the relay is not energized.

What is the difference between contactor and breaker?

An electronic contactor is a simple switching device, whereas the circuit breaker is a protective system. The primary function of a contactor is controlling the power. A circuit breaker does the protecting. Contactor works under normal situations.

When the contactor coil is de energized?

De-energizing the coil causes it to de-magnetize, releasing the armature and enabling a return spring inside the contactor to snap all three contacts to the open (off) position.

Article first time published on

What is the main difference between a relay and a contactor?

A contactor joins 2 poles together, without a common circuit between them, while a relay has a common contact that connects to a neutral position. Additionally, contactors are commonly rated for up to 1000V, while relays are usually rated to only 250V.

What is electromagnetic contactor?

Electromagnetic Contactor is a single pole heavy duty contactor designed to be used on traction vehicles. In order to work efficiently both AC and DC circuits, the contactors are equipped with arc blow-out circuit.

What are the advantages of magnetic contactor over a manual switch?

The various advantages are listed as follows: 1) Magnetic control permits installation of power contacts close to motor whereas the actuating control device i.e., a push button switch could be located away from the motor in a position most convenient to the operator.

Do contactors and relays matter?

Relays and contactors are very effective components for switching electrical power as long as they’re specified correctly, which means getting the right coil voltage (including AC and DC) and sizing the contacts correctly.

Is a contactor coil wired like a load or a switch?

They are wired in circuits exactly like switches and they behave like switches because they are switches. Relay coils are loads; specifically, solenoids.

What is the main difference between a relay and a contactor and between a contactor and a magnetic motor starter?

RelaysContactorRelays are switching devices used in any control circuit for checking a condition or multiplying the number of contacts available.Contactors are switching devices used to control power flow to any load.Relatively smaller in sizeLarger when compared to Relays

What is the difference between a motor starter and a contactor?

A contactor is really just an overgrown relay. … The contactor applies voltage to a contactor coil to close the contacts and to supply and interrupt power to the circuit. A motor starter is simply a contactor PLUS an overload relay and is rated by motor HP or amperage.

What is 13 and 14 on a contactor?

Many contactor manufacturers use the designations A1 and A2 for the terminals that connect power to the magnetic coil. Likewise, many manufacturers use the designations 13 and 14 for the terminals of normally open auxiliary contacts. Auxiliary contacts are operated by the magnetic coil just like the main contacts.

What is contactor rating?

Ratings. Contactors are rated by designed load current per contact (pole), maximum fault withstand current, duty cycle, design life expectancy, voltage, and coil voltage.

What do you mean by switchgear?

What is switchgear? Electrical switchgear refers to a centralized collection of circuit breakers, fuses and switches (circuit protection devices) that function to protect, control and isolate electrical equipment.

What is the difference between contactor and fuse?

To overcome the fault current breaking limitation of contactors, contactors are often used in combination with fuses. The contactor interrupts overload currents while the fuse interrupts fault currents.

Is a circuit breaker a contactor?

The main difference between electrical contactor and circuit breaker is, a contactor is an electrically controlled switch that makes contact to connect the load with the power supply whereas a circuit breaker is an electrical protective device that breaks contacts to disconnect the load from the power supply during a …

What is vacuum contactor?

In contrast, a vacuum contactor is a device that contains electrical contacts inside a sealed “vacuum interrupter” called a vacuum bottle. This sealed environment in which the switching takes place allows for a fast, clean “make/break” action of the contacts in harsh, dirty environments.

When should you use a relay on a car?

Relays are often used in circuits to reduce the current that flows through the primary control switch. A relatively low amperage switch, timer, or sensor can be used to turn a much higher capacity relay on and off. Another primary use for relays is when upgrading to halogen headlights on an older car.

What is difference between relay and switch?

You are correct that a relay is basically just a switch, but it’s a switch operated via remote control, so to speak. A regular switch controls electrical current by connecting or breaking the path of either the positive side of a circuit (most common) or the negative side of a circuit.

What is the criteria to select the contactor?

The choice of contactor is dependant upon many parameters i.e. operating voltage, size of contacts, number of operations, ambient temperature, type of load supplied etc. Loads are categorised into various AC ratings, (AC1, AC2, AC3 etc.) and the higher the AC rating the more inductive the load becomes.

What is 3phase contactor?

A three-phase contactor is an electronic device used to turn power on or off at a three-phase load. These devices are used when the voltage requirements of the load exceed the power-handling capability of a mechanical relay. … This low-voltage signal can be controlled by an electrical relay or a computer.

What is the purpose of an auxiliary contact?

Auxiliary contacts are mainly used to signal switching or malfunction states, for interlocking circuits or logic and sequence controls with low to high loading. Many protection or control devices have additional auxiliary contacts.

Is a relay the same as a capacitor?

You will often see capacitors placed across the coil contacts of a relay. A capacitor takes some time to charge up, so it can be used to make a time delay relay. Warning: A capacitor and a relay coil (which is basically an inductor) are both energy storage devices.

Why do we use magnetic contactor?

Magnetic contactors are used in the electric motors to balance the change in frequency of the motor or the state of the motor which can be termed as the switching of the motor from ON and OFF state. … Magnetic contactors act as a safeguard to protect the power supply and the motor.

What type of magnet is a contactor?

Magnetic contactors are a form of electrical relay found on most electrically powered motors. They act as a go-between for direct power sources, and high-load electrical motors in order to homogenize or balance out changes in electrical frequency which may come from a power supply as well as to act as a safeguard.
